Autel Alpha is an intelligent industrial drone for multi-purpose. Boasting significant enhancements in autonomous flight capabilities, anti-interference capabilities, obstacle avoidance capabilities, video transmission technology, and battery systems, it injects robust performance into the flight platform.
With a foldable design and IP55-rating level, it tackles challenging environments. The built-in RTK dual-antenna system ensures precise control within millimeters when carrying out the missions.Paired with the next-gen DG-L35T gimbal, it integrates a 560x hybrid zoom camera, dual thermal imaging cameras, a visible light wide-angle camera, and a laser rangefinder. The dual thermal imaging cameras meet the needs of both short-range overview and long-range detail observation, achieving distant operation scenarios with unobstructed personnel recognition within an 8-kilometer range, providing more professional and comprehensive solutions for applications such as public safety, energy inspection, and emergency management.
Specification
| Weight (including battery, gimbal camera, and propellers) | 6340g |
| Max. Payload | 3000g |
| Dimensions | 1205*980*278mm (unfolded, incl. propellers) 780*568*278mm (unfolded, excl. propellers) 455*263*248mm (folded, excl. propellers) |
| Max Flight Time (windless) | 40mins |
| Max Horizontal Speed (windless near sea level) | 25m/s |
| Max Wind Resistance | 12m/s |
| Operating Frequency | 2.4GHz/5.2GHz/5.8GHz/900MHz |
| IP Rating | IP55 |
| Max Transmission Distance | 12.4 miles (20km) |
| GNSS | GPS+GLONASS+BeiDou+Galileo |
